LCD Panel

Display size

Brightness(Typical)

NTSC

Contrast(Typical)

Active Area(mm)

Pixel Pitch(mm)

Resolution (H x V)

Aspect Ratio

View Angles LR,UD(CR>10)

Display Colors

15.6"

220cd/m2 (Typ)

72%

800:1 (Typl)

345.60X194.40mm

0.09(H) x 0.09 (V)

1920 x 1080

16:9

H 170°/ V 170°

16.7M colors

PC Input Range

Vertical Freq.

Max. display frequency
(Resolution H*V/Fv)

58 to 62Hz

1920 x 1080 /60Hz

Rotate

G-SENSOR

Rotate Angles

NA

NA

Interface

Input 1

Input 2

Input 3

Input 4

TYPE-C x 2(Full-featured USB-C）

Mini HDMI(1.4)  x 1

NA

NA

Output Terminal

Earphone

Speaker(Typic )

Earphone x 1

1W*2(8Ω)

Power

Consumption(Typical)

PD POWER

Power Mode
Indicator Light

On: ≤18W
Standby≤0.5W, Off≤0.5W

 DC: 5V-3A/9V-3A/20V-1.5A

Power on : GREEN (LED)
Power saving : RED (LED)

Operating Condition

Temperature

Humidity

0℃ ～ 40℃

20% ~ 85%, non-condensing

Physical

Dimension(W*D*H)

Packing Dimension(W*D*H)

Net Weight

Gross Weight

Tilt

VESA Mounting

Swivel

Pivot

Kensington Lock

VESA Mounting

359.8 x 227.1 x 100mm

401 x 272 x 110mm

0.97kg

1.92kg

90∘~ 45∘, 0∘

NA

NA

NA

NA

NA

Controls

Front Control

On Screen Display

Color

Preset Mode

Menu, Bri (-), Vol(+)  Auto/Enter, Power (Key)

 Standard OSD format

9300,6500, User Mode

Standard,TXT, Movie, Game

TOUCH

Touch Screen

Multi touch

Touch Panel

NA

10Points

G+FF

Accessory

Adapter

Type-c Cable

Mini HDMI-HDMI Cable

USBA-Type-c Cable

User Manual(Paper)

Sleeve

YES( DC: 5V-3A/9V-3A/20V-1.5A)

 x 1（1.0M）

 x 1（1.2M）

OPTION

YES

YES

Loading with pallet

40' Standard

20' Standard

3998

2398

Color Plan

Black

Carton Box

Standard

Certification

TBD

HDR

YES

OD function

YES
