Model

Mini-LED Local Dimming Zones

UF32AQH-ST

576 Zone HDR 1400

OC

Panel Type

Curvature

Proportion

size

Display size (H * V)

Resolving power

CSOT SG3151G02-3（2560 x 1440 QHD/165HZ/3.5%) Fast LCD

HVA

Plane

16:9

31.5"

697.344 (H) x 392.256 (V)

2560 x 1440

Refresh rate

OC refresh rate

Whole machine refresh rate (overclocking)

60HZ(Typ)165HZ(Max)

NA

Backlight type

Number of partitions

mini-LED

576 Zone

Display screen

(module)

brightness

Uniformity

Design maximum value (Normal)

Design maximum value (Normal)

9 points uniformity

Maximum brightness of HDR1400 test software center ≥ 1400 nit

Maximum brightness of SDR center  (100/50)  Min 700 nit Typ 800nit

Min 300 nit  Typ 350 nit （Brightness 50 Contrast 50）

Min 90% Typ95%

Default color temperature (factory color temperature)

7000K

contrast ratio

static state

dynamic

3500:1(TYP)

10 million level

chromatic number

1.07G （10bit)

colour gamut

DCI-P3 (CIE 1976 coverage)

Adobe RGB (CIE 1976 coverage)

sRGB (CIE 1976 coverage)

Min 95% Typ 97%

Min 95% Typ 97%

Min 99% Typ 100%

HDR

HDR1400

△E

Average value ＜ 2; Maximum value ＜ 5

Viewing angle (horizontal/vertical)

178°/178°

response time

OC response time (GTG)

OD acceleration response time (GTG)

5ms(Typ)10ms(Max)（165HZ)

2ms

Electronics

Main chip

HDR

MPRT

Port mode

Port (standard configuration)

Port1

Port2

Port3

Port4

Port5

Port6

Port7

Port8

Port9

Port10

Wireless screen projection

V-BY-ONE Interface

Fan

Horn specification

input voltage

adapter type

Adapter Color

Energy efficiency grade

MST9804

Yes

NO

Vertical Port （Back Out Port）

TYPE-C(15W)+USB2.0+2HDMI2.0+DP1.4+AUDIO+DC

No

No

USB2.0-A

HDMI2.0

HDMI2.0

DP1.4

No

AUDIO OUT

DC IN

Type-C  charge 15W

No

No

No

No

DC 24V  7.5A

Desktop adapter

black

Primary energy efficiency

Power waste

AC input power consumption

Standby power consumption (maximum)

180W Max

Shutdown 0.5W; Standby (sleep) 1.2W

Key

Indicator mode

5 key touch the membrane key

Red and blue; Blue on, red on standby.

Safety regulations

CCC certification

Energy efficiency certification

Low Blu ray certification

Yes

Yes

NO

Appearance color

b/w

Structure

Dimensional

outline

Weight

VESA Compatible

Base functions

With base

W/O BASE

box specification

bare weight（W/O BASE）

Net weight

Gross weight

Wall hanging size

Wall mounted accessories

Tilt forward and tilt backward

Lifting height

Left and right rotation angle

Vertical rotation angle

714.6*593.4*235.3 mm

714.6*421.7*66.9 mm

686mm*204mm*445mm

6.2kg

7.7kg

10.8kg

75*75MM

Stud M4*8 H:18mm

+5°/-15°

120mm

±25°

0~90°

Software

                                UI interface

                              Language Menu

                              major function

Customized UI

(Default: Simplified Chinese) Simplified Chinese/English

1. FreeSync（Adaptive-sync)

2. Over Drive

3. MPRT（NO）

4. GamePlus

5. Gaming LED

6. Scene mode

7. Professional model

8.6 axis

9. Gravity induction（NO）

10.HDR1400

11. PIP/PBP

12.USB  upgrade

13.USB Switch

14. Hotkey Setting

15. Gamma

Storage and use

Storage temperature

working temperature

Operating humidity

Storage humidity

Altitude

-20ºC~60ºC

0ºC~40ºC

10~85%RH

5~90% (no condensation) (40 ℃)

≤5000m

Accessories

Manual

Adaptor

Power cord

DP cable

Others

*1

*1

*1

*1

Depends on cutomization requirment

Container Loading(unit)

20' GP Container Unit Load w/o Pallet （PCS)

40' GP Container Unit Load w/o Pallet （PCS)

40' HQ Container Unit Load w/o Pallet （PCS)

20' GP Container Unit Load with Pallet （PCS)

40' GP Container Unit Load with Pallet （PCS)

40'HQ Container Unit Load with Pallet （PCS)

288

576

688

224

448

496
