Refresh Rate

OC

Overfrequency

144Hz

NA

Backlight type

ELED

Brightness Power

Currency

Voltage

640mA(TYP)

59V(TYP)

Brightness

Design Value

Factory Control Value（typ）

300(MIN)350(TYP)

Customer Software Request Value(Min 250)

Default Color Temperature

6500

Contrast Ratio

Static State

Dynamic State

800（MIN)1200(TYP)

Millions

Pixels

16.7M

Colour Gamut

sRGB

NTSC

DCI-P3

Adobe RGB

90%

68%

70%

70%

HDR

NA

View Angle（H/V）

178°/178°

Response Time

OC （GTG）

OD Accelerate Response（GTG）

8ms(TYP)

3ms

I/O Prts（Standard）

Port1

Port2

Port3

Port4

Port5

Port6

Port7

MPRT

Remote Control

Loudspeaker

Power Input

Power Supply

Energy Efficiency Level

DC+HDMI+DP+Type-C+HUB+USB*2+Audio

HDMI2.2

DP1.4

Type-C（3440X1440@165Hz +PD+USB）

HUB  (USB2.0 TYPE-B）

USB 2.0-A

USB 2.0-A

Audio output

yes

selected

4Ω/2W

AC 100-240V

External power Adapter:24V 7A

Level II

Power

AC Input Power

Stand-by Power Consumption（Max）

148W Max

Indicator Light Mode

Power on : Blue (LED)

Structure

Appearance Color

Black

Unit Size      （Design）

Distance (OC to Mid-Frame）

Distance(AA to Mid-Frame)

Black Border Width

Unit W/stand

Unit W/O stand

Packing Size

0.7mm

8.5mm

6.0mm

944.8*534.4*290.0mm

944.8*420.4*64.0mm

1182*186*514mm

Weight

Weight（W/O Stand）

Net Weight

Gross Weight

8.9kg

10.95kg

13.95kg（Etd）

VESA Size(WxH)

VESA Demension

Vesa Assessory(Fasten)

100*100mm

Screw

Stand Functions

Angle

（Forerake /Back-Lean）

Up and Down（Vertical）

Rotation Angle（L/R）

Ground Clearance（mm）

Forerake ：5°    Lean Back：15°

10cm

 -15°~15°

120mm

Software

Control Mode

Language Menu

Common Blue/White OSD

10 Countries Language(Defaut:Chinese)

Main Functions

Color Temperature（Cold、Warm、User）

Low Blue Light Control

6 Contextual Models

DCR

Multiple-Language Menu

Backlight ajustment w/o flicker

FPS/RTS Game Mode with 1 key-switch

GAME PLUS

FreeSync

Storage and working Environment

Working Temperature

Storage Temperature

Working Humidity

Storage Humidity

Altitudes

0ºC~40ºC

-20ºC~60ºC

10~85%RH

5~90%(No Freezing under 40ºC ）

≤5000m

Assessory List

USER MANUAL

Stand Assembling Guide

Power Adapter with Power Cable

STAND SCREWS

Certificate of Qualification

yes

yes

yes

yes

yes

Container Loading(unit)

20' GP Container Unit Load w/o Pallet

40' GP Container Unit Load w/o Pallet

40' HQ Container Unit Load w/o Pallet

600

1275

1530
